Pulleys

Alby is a single sheave pulley with aluminum swinging side plates and aliminum wheel. Taper bush lock pulley, high efficiency (93%). It works with ropes up to 26mm.

High load, up to 50 kN

Conceived for arboriculture, treeclimbing.

High quality product, made in Italy!

Max Rope Diameter: 8 mm

These specialized pulleys are built for our AZTEK Rescue System. Machined from a solid block of high strength aluminum, they are engineered to handle high loads. The swivel eye connection eliminates twisting of the rope and can accommodate up to three carabiners. Each block is a different color to ensure differentiation during operation.

EN 12278

The AZTEK OMNI pulley blocks and sheaves are machined from solid aluminum, feature swivel connection points, and utilize high-efficiency bearings. These pulleys were developed in the early 2000s by Reed Thorne of Sedona based Ropes That Rescue. The AZTEK system has become a valuable multipurpose tool of rescue and technical rope access practitioners. The AZTEK pulleys are offered individually or included in our AZTEK ProSeries System (item # 500104).

Note: The Slate blue pulley includes the AZTEK quick release pin and the Orange pulley comes with the side becket cover and screw.

Specs

• Weight: 7.9 OZ (226 G)

• Sheave: Aluminum

• Sheave Tread Size: 1 X 0.4 IN (26 X 10 MM)

• NFPA Rating: Technical Use

• 3 Sigma MBS: 43 KN (9,666 LBF)


Originally developed by Reed Thorne of Arizona-based Ropes That Rescue, the AZTEK (Arizona Technician’s Edge Kit) is used globally and offers more than 100 rigging solutions in a bag. As one of the most versatile tools used in rope rescue, the system reflects the philosophy of keeping rigging equipment simple, efficient, non-specialized, light and small.

The design of the CMC AZTEK ProSeries^® LT System (Load Tender) leaves no detail ignored. The more compact ‘LT’ version of the AZTEK offers 28 feet of 8 mm AZTEK ProSeries^® Cord that can extend the set-of-fours up to 6 feet, providing a 4:1 or 5:1 mechanical advantage with a minimum breaking strength (MBS) of 38 kN (8,542 lbf). The LT system includes (2) ProTech™ Aluminum Auto-Lock Carabiners w/ removable keeper pin – 29 kN (6,519 lbf) for attaching to the swivel ends. (Note: Included carabiners must be installed by the user and are UL Classified to NFPA 1983 – Technical Use)

USES: Whether using the set-of-fours (SOFs) as a quick 4:1 or 5:1 M/A for a multitude of rigging applications, or for pick-off rescues, the versatile AZTEK ProSeries LT System gives rescuers and rope access technicians endless rigging solutions in a bag, including:

• Quickly adjusts litter attendant position, low/high
• High-angle attendant tether
• High-angle litter scoops
• Solo pick-off
• Personal mechanical advantage
• Knot passing
• Aids in correcting disoriented equipment under load
• Effortlessly transfer loads
• Promptly establish dynamic fixed brakes
• Pre-tensioned back-ties
• Redirect anchors
• Load-releasing hitch
• Tensioned guying

Includes

The AZTEK ProSeries LT System comes assembled in an attachable carry bag and includes:

• CMC AZTEK Omni Pulley Set – UL Classified to NFPA 1983 (2017 ED)
• Quick Pin for AZTEK Omni Pulley
• AZTEK ProSeries^® Cord – 28 feet of 8 mm hi-viz orange, 15 kN (3,372 lbf);
  Sewn-Eye Termination -12 kN (2,698 lbf)
• (2) ProTech™ Aluminum Auto-Lock Carabiners w/ removable keeper pin – 29 kN (6,519 lbf), not installed
• AZTEK Bound-Loop Prusik, blue (6 mm) – 9 in
• Storage bag with quick-connect attachment (red)

Specs

The innovative AZTEK ProSeries® Pack can be carried around waist or thigh.

Specs

• The AZTEK System collapses and stores into two separated compartments; one side houses the AZTEK Omni Set-of-Fours, the other side holds the personal travel restrict end
• Constructed from tough Cordura® nylon material
• Rugged mesh-panel bottom allows wet components to dry quicker
• Double-zippered top compartments offer quick and easy access to either side
• Unique Garage Pocket™ conceals cord that bridges from the two compartments to protect it from UV exposure and trail snags
• Outside zippered pocket is ideal for carrying small items such as a field guide, cell phone, exam gloves, trauma sheers, or multi-tool
• Gear loop holds up to four rescue-size carabiners
• Exterior reflective strip significantly increases visibility
• Designed with an integrated, adjustable harness attachment strap so it can be worn around the waist or thigh
• Tension-lock buckles tighten and hold the adjustment securely, while allowing quick pack rotation around the hips for access

Improved! As one of the most versatile tools in rope rescue, the CMC AZTEK ProSeries System reflects our philosophy of keeping rigging equipment simple, efficient, light, compact, and multi-purpose. Originally developed by Reed Thorne of Arizona-based Ropes That Rescue, the AZTEK (Arizona Technician’s Edge Kit) is used worldwide and offers more than 100 rigging solutions in a single bag. The CMC AZTEK ProSeries System is made in USA of US and foreign components.

This system now includes an updated AZTEK ProSeries Pack that has improved fabric durability, new reflective piping, and a fresh OD Green color. The pack is feature rich with 1000D nylon/Tarpaulin construction for abrasion resistance, mesh panel for ventilation and drying, Garage Pockets™ to protect cord, double-zippered top compartments, and tension lock buckles for carrying on the waist or thigh. Note: product videos may show previous pack model (no longer available in Coyote color).

Features

The CMC AZTEK ProSeries System is the first AZTEK system to be UL Classified to NFPA 1983 (2017 ED) – General Use – Manufactured System. The system is thoughtfully designed to support rescue teams and each component has been tested and proven to work efficiently in a multitude of lab and field scenarios. Everything comes pre-rigged and fully assembled for immediate deployment.

The set-of-fours includes 15.2 m (50 ft) of 8 mm AZTEK ProSeries Cord, which is CMC’s high-performance 100% nylon blend. These can extend to 3.6 m (12 ft) while providing a 4:1 or 5:1 mechanical advantage with a Minimum Breaking Strength (MBS) of 38 kN (8,542 lbf).

For a personal edge travel-restrict with nearly 15.2 m (50 ft) of adjustable travel, attach the carabiner of the personal end of the system to an appropriate anchor and restrict edge travel using the integrated Purcell connected to your harness. The sleeved web edge-pro helps protect the cord around anchors with abrasive surfaces.

Uses

Whether using the set-of-fours (SOFs) as a quick 4:1 or 5:1 M/A for a multitude of rigging applications, or for personal edge protection, the versatile AZTEK ProSeries System gives rescuers endless rigging solutions:

• Quickly adjusts litter attendant position
• High angle litter scoops
• Solo pick-off
• Easily pass knots
• Correct disoriented equipment under load
• Effortlessly transfer loads
• Promptly establish dynamic fixed brakes
• Pretensioned back-ties
• Redirect anchors
• Establish travel restriction
• Dynamic directionals
• Dynamic lowers
• Hauling systems
• High angle attendant tether
• Load-releasing hitch
• Personal mechanical advantage (PMA)
• Solo pick-off
• Tensioned guying

Contents

The CMC AZTEK ProSeries System comes fully assembled in the AZTEK ProSeries Pack and includes the following:

• CMC AZTEK Omni Pulley Set, (one blue, one orange) – UL Classified to NFPA 1983 (2017 ED)
• Quick Pin for AZTEK Omni Pulley
• AZTEK ProSeries Cord – 15.2 m (50 ft) of 8 mm hi-viz orange, 15 kN (3,372 lbf), Sewn-Eye Termination – 12 kN (2,698 lbf)
• AZTEK Edge-Pro Tubular Webbing, blue .6 m (24 in)
• ProTech™ Aluminum Auto-Lock Carabiner w/ removable keeper pin – 29 kN (6,519 lbf)
• AZTEK Bound-Loop Prusik, orange (6 mm) – 9 in
• AZTEK Bound-Loop Prusik, blue (6 mm) – 9 in
• AZTEK Bound-Loop Purcell, blue (6 mm) – 42 in
• Maillon Rapide Quick Link, Oval (7 mm) – 27 kN (6,070 lbf)

Single pulley with mobile side plates, low friction ball bearing, integrated blocker, designed for climbing and rescue.

Suitable for the recovery of materials in a wall, conceived for the preparation of single and double hoist for rescue and self-rescue.

For ropes up to 12mm diameters.

High quality product, made in Italy!

Ultra-light pulley / rope clamp (only 80 g!) designed for work, rope climbing maneuvers, rescue and self-rescue situations.

Specs

• Maximum holding strength with ability to self-equalize and distribute the load
• Able to be divided into multiple safety systems
• Increased holding power and minimal soil disturbance due to anchor rod
• Allows easy attachment of additional holding support if required
• Available as a Single StayK or as a Kit of three StayK

Double pulley with locking cam, designed for use as a ratchet pulley in a lightweight haul system with the UP ROLL pulley.

Specs

• Anodized light alloy side plates
• Cast stainless steel cam
• Alloy pulleys with ball bearings
• Freelock system allows one-handed cam action

The patented locking mechanism in our updated CSR2 Pulley is easy to release under load, creating much greater efficiency with the lowering and raising necessary to a confined space rescue. The machined aluminum swivels at both ends of the system eliminate any potential twisting of the lines. This system is also an excellent choice for confined space entry or rope access work where a heavy-duty pulley system is desired. Systems comes completed reeved and packed into its storage bag ready to use.

Specs

• All-new stronger, lighter-weight design
• Available witheither11 mm (7/16 in) or12.5 mm (1/2 in) Static-Pro Lifeline
• Systems are UL Classified toNFPA 1983 (2017 ED) General Use
• CSR2 Pulley MBS 46 kN (10,341 lbf)/CSR2 Double Pulley MBS 45 kN (10,116 lbf)
• Machined from solid block of aircraft-grade aluminum
• Includes (2) ProSeries Aluminum Screw-Lock Carabiners,MBS 47 kN (10,566 lbf) -General Use
• Made in USA

Includes

• 11 mm (7/16 in) Static-Pro Lifeline, Blue (1 x 200 ft)or 12.5 mm (1/2 in) Static-Pro Lifeline, Red (1 x 200 ft)
• CSR2 Pulley
• CSR2 Double Pulley
• ProSeries Aluminum Screw-Lock Carabiner (2)
• #3 Rope Bag, Red

Video

Pat. 7,419,138

The design of our redesignedCSR2 (Confined Space Rescue) Pulley is stronger yet lighter and incorporates 7/16 in (11 mm) to 1/2 in (13 mm) lifesafety rope. Ideal for industrial applications as well as many rescue operations, the CSR2 uses our proprietary, patented locking system, which eliminates a toothed cam or Prusik so it can be easily and safely released while under load. (The absence of the toothed cam means that even if the system is fully collapsed and pulled tight, it can still be released easily. Systems using a toothed cam must be raised even further before the cam can be released, which can be impossible if the system is fully collapsed without thinking about this problem ahead of time causing potential problems with the load on the system becomingstuck.) An integral thrust-bearing swivel reduces torque by aligning the pulley with the load, thereby increasing efficiency and safety. Its larger size allows for the easy application of rescue-size carabiners.

Machined from a solid block of aircraft-grade aluminum, the CSR2 features a high-strength aluminum side plate, sealed bearings and anodized aluminum sheaves. The side becket location allows for maximum lift height and full retraction of the system, and a removable becket cover facilitates changing out lifeline with sewn terminations.

Specs

• All-new stronger, lighter-weight design
• Compatible with 11-13mm life safety rope
• Meets NFPA 1983 (2017 ED) General Use
• CSR2 Pulley MBS 46 kN (10,341 lbf)/CSR2 Double Pulley MBS 45 kN (10,116 lbf)
• Machined from solid block of aircraft-grade aluminum
• Made in USA

Max Rope Diameter: 13.0 mm

Our Single Prusik-Minding Pulleys and Double Prusik-Minding Pulleys are specifically designed to keep the progress capture prusik from getting sucked up into the pulley system and allowing a rescuer to tend to another task. Both single and double versions are compatible with ropes up to 13 mm. All Sterling pulleys are constructed from high-strength aluminum side plates and feature a sealed ball bearing sheave that helps keep out dirt and grit.

This lightweight, full-strength, Prusik-minding pulley is ideal for mountain rescue, swiftwater rescue, or technical teams where equipment weight is a significant consideration. By machining the side plates, the thickness of the metal can be varied to maximize the strength-to-weight ratio, a process that cannot be done with traditional bent metal side plates. Sealed ball bearings provide high efficiency, and aluminum side plates protect the rope. An extremely low-profile stainless steel axle assembly reduces snagging on rocks, roots, and uneven surfaces. Designed for lifeline up to 1/2 inch (13 mm) in diameter.

Available in Single or Double versions.

Do not load a single side only of a double sheave pulley.

Specs

Aluminum pulley with single wheel, mobile side plates and high efficiency (96%) ball bearing .

Equipped with two attachment points for use in complex lifting systems.

For ropes up to 16 mm diameter.

High quality product, in Italy!

Aluminum pulley with single wheel, mobile side plates and high efficiency (96%) ball bearing.

Equipped with two attachment points for use in complex lifting systems.
For ropes up to 16 mm diameter.

High quality product, in Italy!

*The black color is particularly appreciated for all uses where the equipment must be not very visible (military use, theater and cinema, acrobatic shows, etc ...).

Low friction pulley fitted with a locking device that can be engaged and disengaged through the special pawl.

Compact and lightweight, conceived for mountaineering and rescue.

Properly used in recovery, it becomes fundamental for the preparation of simple or double hoists in rescue and self rescue.

Miniblock belongs to the ultra compact “Futura” family of blockers, which can be used in case of emergency and for climbing.

High quality product, made in Italy!

No detail has been overlooked in our redesign of the ProSeries Pulleys.Built workhorse tough to deliver years of dependable service, these HD (Heavy Duty) Pulleys are loaded with enhanced features.

• Large high-efficiency anodized aluminum sheave
• High-strength sealed bearings that minimize loss of mechanical advantage and will deliver optimum performance haul after haul
• Side plates constructed of machined aircraft-grade aluminum,withsmooth rounded edges to minimize rope wear
• Wide attachment point that supports multiple rescue-size carabiners
• PMP (Prusik-Minding Pulley) bottom shaped for maximum efficiency with Prusik hitches and also works well with mechanical rope-grabs
• Note: Do not load a single side only of a double-sheave pulley.

Specs

• Type: HD2
• item # 300441
• Product Weight 367 g (13 oz)
• Sheave Tread Size 57 x 13 mm (2-1/4 x 1/2 in)
• Pulley Dimensions (H x W) 14.5 x 10.75 cm (5-3/4 x 4-1/4 in)
• Type Single
• Color Gray
• NFPA Rating General Use
• 3 sigma MBS 56 kN (12,588 lbf)

• Type: HD2 Double
• item # 300442
• Product Weight 605 g (1.3 lb)
• Sheave Tread Size 57 x 13 mm (2-1/4 x 1/2 in)
• Pulley Dimensions (H x W) 16.5 x 9.5 cm (6-1/2 x 3-3/4 in)
• Type Double
• Color Gray / Red
• NFPA Rating General Use
• 3 sigma MBS 56 kN (12,588 lbf)

• Type: HD4
• item # 300461
• Product Weight 850 g (1.9 lb)
• Sheave Tread Size 95 x 13 mm (3-3/4 x 1/2 in)
• Pulley Dimensions (H x W) 19.75 x 14 cm (7-3/4 x 5-1/2 in)
• Type Single
• Color Red
• NFPA Rating General Use
• 3 sigma MBS 46 kN (10,340 lbf)

Details

• Versatile:
  - allows pickoffs, making a releasable anchor, tensioning a system...
  - can be coupled with an I'D descender to make a reversible rescue kit to pick off and evacuate a victim

• Hauling effectiveness:
  - 4:1 mechanical advantage allows user effort to be divided by 4
  - excellent efficiency due to sheaves mounted on sealed ball bearings
  - deployment possible even when the distance to the anchor is very short, thanks to the extreme compactness of the collapsed system
  - 8 mm lightweight rope The mechanical advantage guarantees a good grip.

• Quick and easy to deploy:
  - kit always ready to use, thanks to the flexible cover that prevents any risk of tangling
  - haul end immediately identifiable, thanks to the yellow color of the end of the cover
  - the ends of the cover hold the connectors in position to facilitate clipping

• Comes with two Am'D TRIACT-LOCK auto-locking carabiners

• Available in three lengths: 1, 2 and 5 m

• JAG and JAG TRAXION pulleys also available separately for making long haul systems (e.g. confined space descent/ascent system)

Specs

• Material(s): aluminum, nylon, polyurethane
• Rope diameter: 8 mm
• Certification(s): EAC
• Sheave type: sealed ball bearings
• Working load: 6 kN
• Breaking strength: 16 kN
• Efficiency: 91 %

Our Kootenay Ultra Pulley is the most functional, versatile knot-passing and high-strength tie-off pulley available. For high lines, the rigging holes allow for optimum separation of tag lines and hoist ropes for reeving variations. For English and Norwegian reeves, a greater spread between the hoist pulleys significantly reduces the chance of inadvertent spinning of the load. Separate rigging holes make rigging easier and also prevent carabiners from binding against each other. For high-strength tie-offs, the integrated sheave-lock pin inserts easily into the sheave-lock hole from its stowed axle position. The strong, durable anodized aluminum sheave is fitted with sealed ball bearings for long wear and high efficiency.

Specs

Max Rope Diameter: 11.0 mm

The Micro Pulley is a CE-certified, lightweight aluminum pulley with fixed side plates that accommodate ropes up to 11mm.

EN 12278

Quantity x6

Max Rope Diameter: 11.0 mm

Our small aluminum pulleys—the MDP and MSP—are strong and lightweight, making them ideal for mini haul systems. The MSP is a single pulley and our MDP is a double rope pulley; both accept ropes up to 11 mm in diameter.

Quantity x2

Max Rope Diameter: 11 mm

Our small aluminum pulleys are strong and lightweight, making them ideal for mini haul systems. Sealed bearings operate smoothly and consistently with ropes up to 11 mm in diameter.

EN 12278

Quantity x3

Compact aluminum pulley with double wheel, mobile side plates and high efficiency (91%) ball bearing.

Equipped with two attachment points for use in complex lifting systems.

For ropes up to 11 mm diameter.

High quality product, in Italy!
